Microchip launches dsPIC DSC-based integrated motor drivers

26th February 2024
Harry Fowle
0

Microchip has launched a new family of dsPIC Digital Signal Controller (DSC)-based integrated motor drivers.

These devices incorporate a dsPIC33 digital signal controller (DSC), a three-phase MOSFET gate driver and an optional LIN or CAN FD transceiver into one package. A significant benefit of this integration is a reduction in component count of the motor control system design, smaller printed circuit board (PCB) dimensions and reduced complexity. The devices are supported by development boards, reference designs, application notes and Microchip’s field-oriented control (FOC) software development suite, motorBench Development Suite V2.45.

“Automotive, consumer and industrial designs are evolving and require higher performance and reduced footprints. These expectations often come at a higher expense and increase in dimensional size,” said Joe Thomsen, vice president of Microchip’s digital signal controllers business unit. “By integrating multiple device functions into one chip, the dsPIC DSC-based integrated motor drivers can reduce system-level costs and board space.”

The integrated motor driver devices can be powered by a single power supply up to 29V (operation) and 40V (transient). An internal 3.3V low dropout (LDO) voltage regulator powers the dsPIC DSC, which eliminates the need for an external LDO to power the device. Operating between 70—100 MHz, the dsPIC DSC-based integrated motor drivers provide high CPU performance and can support efficient deployment of FOC and other advanced motor control algorithms.

To learn more about Microchip’s growing portfolio of integrated motor drivers visit the dsPIC DSC-Based integrated motor drivers webpage.
