Pasternack’s new impedance-matching pads

28th May 2024
Harry Fowle
0

Pasternack has announced its latest product, matching pads for 50-ohm and 75-ohm transmission lines. They provide seamless transition between the two types of transmission lines.

These pads ensure optimal performance across a variety of RF applications and underscore Pasternack’s commitment to providing high-quality, innovative solutions tailored to the evolving needs of the telecommunications, broadcast and defence industries.

The matching pads feature BNC, F-type, N-type, and SMA connectorised designs, making them versatile for integrating into existing systems with ease. The pads facilitate 50-ohm to 75-ohm impedance matching as well as 75-ohm to 50-ohm, catering to a broad spectrum of transmission requirements.

With configurations including 50-ohm BNC to 75-ohm F-type among various gender setups, and combinations like 50-ohm N-type male to 75-ohm F-type male, and 50-ohm SMA male to 75-ohm F-type female, the matching pads solve diverse connectivity challenges.

“Operating efficiently up to a frequency of 3 GHz, these impedance-matching pads support the demands of high-speed data transmission and broadcasting, ensuring minimal signal loss and optimised performance in all scenarios,” said Product Line Manager Steven Pong. “By providing a wide range of impedance and connector options, we aim to enhance the flexibility and reliability of RF systems in various industries.”
