The single and dual output drivers can source and sink peak currents of between 2 A to 30 A, while producing matched voltage rise and fall times and low propagation delays.
The gate driver series can be used in a wide range of high-frequency and high-power applications, including power supplies, heat pumps, motor controls and power factor correction (PFC) circuits.
The input of each driver is virtually immune to latch-up, and proprietary circuitry eliminates cross conduction and current ‘shoot through’.
The IXD_600 series can operate with supply voltages from 4.5 V to 35 V and is specified for an extended operating temperature range of between −40 °C and +125 °C.
Depending on whether the gate drivers are dual or single output devices, they can be configured as non-inverting drivers with enable, inverting drivers, or as drivers with one inverting and one non-inverting.
A variety of standard package options, include an 8-pin DIP, an 8-pin SOIC, a thermally enhanced 8-pin SOIC with exposed metal back, 8-pin DFN, 5-pin TO-263, and a 5-pin TO-220.
