Precision high voltage applications such as testing equipment, instrumentation, high voltage inverters, energy storage, and medical equipment require high accuracy high voltage resistors.
For these applications, typical VCR of 200 ppm to 500 ppm lead to significant and unacceptable measurement error. Stackpole’s HCVR is engineered to address these challenges, yielding accuracy of no more than -0.2% to -0.5% over 1000 V change allowing for improved performance and reliability.
The HVCR is available in 1206 and 2512 sizes, in 10MΩ and 100MΩ resistance values, in 1% tolerance and 100 ppm TCR. Stackpole’s manufacturing provides capability for other sizes and resistance values in addition. The HVCR1206 is rated for 1500V working voltage and the HVCR2512 is rated for 3000V.
