Qseven Computer-on-Modules are energy efficient and powerful

1st March 2018
Anna Flockett

Kontron has announced for the first time two new modules in the Qseven form factor at embedded world 2018. Depending on the requirements, the Qseven-Q7AL module is available with Intel Atom, Pentium or Celeron processors, the Qseven-Q7AMX7 module uses the Cortex A7 processor. Both modules support the Qseven 2.1 specifications and are designed for use in industrial environments and at extreme temperatures.

Kontron supports the Qseven form factor to address the installed user base of Qseven to provide a migration path towards modern CPU technology using Kontron products.

The Qseven-Q7AL module is available with Intel Atom processors E3930 (Dual Core), E3940 (Quad Core) und E3950 (Quad Core) with up to 2.0GHz. Thermal Design Power (TDP) ranges from 6.5-12W. Optionally, the module can be equipped with Intel Celeron N3350 (Dual Core) or Intel Pentium N4200 (Quad Core) processors. These offer 2.4GHz at 6W TDP or 2.5GHz at 6W TDP, respectively.

The module can be equipped with up to 8GB DDR3-1867 (-1600) Memory Down (ECC in the variants based on Atom processors) and up to 32GB eMMC 5.0 Onboard Flash storage. The Qseven-Q7AL offers a ninth generation Intel HD Gfx graphics controller. The available interfaces include two SATA 6Gb/s, four PCIe 2.0, a serial interface, HD Audio, one I2S, one I2C, one SPI, one camera interface (2x MIPI CSI), one LPC, one CAN, two USB 3.0 (including USB 2.0), four USB 2.0, and an optional USB On-the-Go (OTG). It supports the Windows 10 IOT Enterprise and Linux operating systems. It can be run at temperatures from 0 to 60°C, or -40 to 85°C for the Qseven-Q7ALi E2 variant.

The Qseven-Q7AMX7 module uses Qualcom/ NXP Cortex A7 Single/Dual i.MX7 processors. It features 2GB DDR3 RAM, two 64GB eMMC 5.0 Onboard Flash and supports two PCIe 2.0 with with Dual Core Processor. Other interfaces include up to five USB 2.0, one USB2.0 OTG, one serial interface, HD Audio, one I2S, one I2C, one SPI, one camera interface (2x MIPI CSI), eight GPIO [0:7] and one CAN. The module supports the Yocto Linux operating system. It is designed for an extended temperature range from -20 to 85°C. Kontron has scheduled the release of further Qseven products in 2018, offering as well a broad portfolio based on the Qseven form factor to its customers.

Security starting in the hardware
The Qseven-Q7AL module supports Trusted Platform Module TPM 2.0 on request. Both modules support the Kontron APPROTECT Security Solution. Based on an integrated Wibu-Systems security chip and in tandem with a specifically developed software framework, application can only be executed on pre-defined devices, furthermore it provides full IP and copy/reverse engineering protection. Kontron APPROTECT Licensing also provides license management to enable demo versions for limited time periods, or activation/deactivation of functions for a limited number of executions for new business models like pay-per-use.
