Authorised distributor DigiKey is now stocking Analog Devices’ TMC5262 fully integrated single-axis stepper motor controller and driver.
It is designed for high-performance motion control applications requiring compact size, high efficiency, and extensive diagnostics.
The device integrates dual 65 V power H-bridges, internal current sensing, a configurable motion controller, and SPI communication, reducing external component count while simplifying system design.
A key advantage of the TMC5262 is its combination of advanced motor control technologies and integrated motion functions. The device supports up to 256 microsteps, includes an eight-point ramp generator for smooth positioning profiles, and offers both SPI-controlled operation and traditional step-and-direction interfaces.
Integrated current sensing eliminates the need for external sense resistors, reducing PCB area and power dissipation.
The TMC5262 also incorporates a broad set of diagnostic and monitoring features, including supply voltage and temperature measurement, sensorless load detection, motor stall detection, and real-time tuning capabilities through its on-chip scope interface.
These capabilities make it well-suited for industrial automation, laboratory equipment, robotics, and other precision motion-control systems where reliability and system visibility are important.
Operating voltage range is 4.5 to 65 V.
Integrated dual H-bridges support up to 4.25 ARMS and a 6 A peak motor current.
Advanced motion control features an eight-point ramp generator, StallGuard+, CoolStep+, StealthChop+, and SpreadCycle technologies
