The new AMT45S pulse transformer from TDK is in stock at authorised distributor Mouser Electronics.
It is designed for power line communication (PLC) circuits in EV charging applications.
This pulse transformer is designed to comply with the European CCS (Combined Charging System) and US NACS (North American Charging Standard) standards for rapid expansion of charging infrastructure.
These standards rely on PLC for charging control, and the performance of the pulse transformer is directly linked to the reliability of overall charging efficiency, charging control communication, and battery performance.
The AMT45S pulse transformer is manufactured using fully automated winding technology. This proprietary process features metal terminals and laser welding to offer low insertion loss and high reliability across the 2 to 30MHz frequency band.
By facilitating miniaturisation, a ferrite and winding geometry, and the lack of a resin coating also provide higher production efficiency, improved quality stability, and greater cost-effectiveness than traditional products.
The AMT45S features a compact 4.7 x 3.4 x 3mm3 (L x W x H) footprint and an operating temperature range of -40 to +125°C.
