Chip inductors are military QPL-approved

26th May 2021
Mick Elliott

A Ceramic Wirewound Chip Inductors series encompassing four devices from Gowanda Electronics is in stock at New Yorker Electronics.

With no internal solder connections, the chip inductors increase reliability in Space/Aero programs.

The Gowanda inductors are also Military QPL-approved, built & tested to meet M83446.

Part of Gowanda’s H-Core Solution, these chip inductors are designed to offer a solution to those facing challenges with their traditional moulded inductors.

In addition to the no internal solder connections, its winding are fully protected by UV, coil forms readily available and they are made in USA with fully automated assembly.

They also possess co-fired terminations and fully encapsulated designs are available for extra durability.

Excellent for high frequency applications, at only 1.20mm x 0.065mm x 0.70mm, the CC0402 is less than 0.05g and is suitable for reflow soldering.

Its capacitance options range from 10nH to 4700nH with DC currency ratings from 220mA to 1000mA and a tolerance of 2%.

It has an operating temperature range of -55°C to +125°C and like all four series it has a flat top cover for ‘pick and place’ and is suitable for reflow soldering.

The CC0603 is available in three tolerance options of 10%, 5% and 2%.

It ranges in capacitance options from 1.8nH to 330nH and DC currency ratings from 179mA to 1000mA.

It is 1.80mm x 1.12mm x 1.02mm and weighs less than 0.05g, and operating temperature ranges from -40°C to +125°C.

The CC0805 has a capacitance range of 2.4 to 2200nH and a DC currency range of 140 to 1000mA with an operating range of -55°C to +125°C.

It is 2.41mm x 1.78mm x 1.52mm with available tolerance options of 10%, 5% and 2%.

The CC1008 is 2.92mm x 2.80mm x 2.28mm and has an operating temperature of -40°C to +125°C.

It ranges in capacitance from 10nH to 4700nH and in DC currency from 220mA to 1000mA. It offers tolerances of 5% and 2%.

All four series ensure low power consumption, high chemical resistance, vibration/shear resistance, electrical and mechanical integrity and durability during handling.

Gowanda also makes implantable device components (human body).

The inductors are made in the USA with fully automated assembly

Applications cover industrial automation & control equipment, instrumentation, medical & diagnostic equipment and devices and test and measurement equipment
