There are two versions including straight-cut probe ends for those that would like to customise the dimensions of the center conductor and dielectric dimensions, as well as pre-stripped probe ends that are ready for immediate use. By soldering the outer conductor to the signal ground and the exposed center conductor to the trace carrying the signal of interest, simple sampling measurements can be made without having to create a separate subassembly circuit board or add a connector to the circuit layout which can take up valuable real estate.
Fairview provides 3 diameters of semi-rigid coax and 3 different lengths from 3 to 12″ to fit a variety of trace widths and applications. All test probe cable assemblies are 100% RF tested to ensure the cable assemblies operate to 6GHz and also to make sure that the SMA connector interface meets the 1.35:1 VSWR specification prior to shipping. To protect the small diameter coax from damage, each part is shipped in a clear protective tube that can also be used for storing the probes for future use.
“Our new semi-rigid test probes provide engineers and designers a convenient, ready-to-use solution for testing their development circuits or troubleshooting and analysing different portions of their circuits,” explains Brian McCutcheon, Vice President and General Manager, Fairview Microwave.
