Time of flight sensor detects objects in 3D

27th July 2023
Mick Elliott

The ZMX 3D time of flight (ToF) sensor from Banner Engineering is now being shipped by authorised distributor Mouser Electronics.

This 3D ToF sensor is designed to measure and monitor peak fill height and volume within a large field of view.

It uses laser and digital imaging technology to detect objects in a wide, three-dimensional field of view.

The sensor features LED indicators, 272 x 208 pixels resolution, 60° x 45° field of view, 12VDC to 30VDC, and 200mm to 2500mm sensing range.

It provides an easy setup- integration, reliability, all-in-one design, self-contained, and monitors an entire sensing region of interest.

Because the sensor can detect items of any size, shape, or orientation, it is an ideal tool for automated industrial applications in which materials, products, or packages accumulate within a defined area.

Typical applications for the ZMX 3D ToF sensor include bin fill and peak height monitoring, overfill detection, pallet height detection and conveyor statistics.
