PowerPax launches miniature 30W DC/DC converters

21st May 2009
ES Admin

PowerPax has announced a range of miniature 30W DC/DC converters. The 30PVRB_LD Series is 40% smaller than the current industry standard package with dimensions of 50.8 x 25.4 x 11.5mm and has a power density of 2.28W/cm3.

These converters are available with either a 24V (18 – 36V) or 48V (36 – 75V), 2:1, nominal input with outputs of 3.3V, 5V, 12V and 15V available. These converters feature a total output tolerance, including line and load regulation, of ±1% with excellent closed loop control providing good stability. Standard features on this series include over-voltage, over-current, under-voltage and Short-circuit protection as well as output trim and remote ON/OFF.

The series features input to output isolation of 1.5kV DC and efficiency of up to 88%. The operating temperature range is -40°C to +85°C with convection cooling and for tougher environments there is an optional external heat sink available. The case of the 30PVRB_LD provides a six sided shield which provides a rugged package and in addition enhances EMI performance.

This product range is design for long life and features the latest SMD technology with an MTBF of greater than 1 Million hours.

These products are a small part of the comprehensive range of DC/DC converters available from PowerPax UK. The DC/DC product series features products from 0.25W to 1kW with wide input regulated, fixed input regulated, fixed input un-regulated, switching regulators and chassis mount converters available. PowerPax UK is continuously adding new products to the range so why not visit us at www.powerpax.co.uk to see what we have to offer.
