OmniOn Power adds to CLP series with 300W power supply

10th May 2024
Harry Fowle
0

OmniOn Power has expanded its CLP series of fanless, open-frame power supplies with the CLP0312FP, a highly efficient, compact solution that provides up to 300W of power in a 2-inch by 4-inch footprint.

The power supplies feature a universal input voltage range of 90-264Vac, a 12V output voltage, and can achieve efficiencies greater than 92%. They also meet the required Class B emission standards for conducted and radiated emissions.

The CLP0312FP helps to meet the growing need for high-power density in applications like the latest networking equipment, including optical line terminals, switches, routers, and private base stations. In addition, its fanless operation, high power derating, and reliability – nearly one million hours of mean time between failures – make it well suited for sealed enclosures such as outdoor telecom equipment.

Applications

Key application areas for this power supply include:

  • Telecommunications equipment
  • Embedded computing
  • Storage systems
  • Industrial equipment

Features

  • Compact size 50.8 mm x 101.6 mm x 36.9 mm (2 in x 4 in x 1.45 in) with density of 25 W/in3
  • Universal AC input range (90 – 264VAC)
  • Output voltage of 12V
  • Maximum output current of 25A@ 12Vout (300W)
  • Full load capability at 65°C and 600LFM airflow with derating at higher temperatures or lower airflows
  • Output overcurrent protection (non-latching)
  • Overtemperature protection (auto restart)
  • Output overvoltage protection (auto restart)
  • Up to 11ms of holdup time
  • Active power factor corrected input
  • Conducted EMI - meets CISPR32 (EN55032) and FCC Class B requirements
  • Compliant to RoHS II EU “Directive 2011/65/EU” and amended Directive (EU) 2015/863.
  • Compliant to REACH Directive (EC) No 1907/2006
  • UL and cUL approved to UL/CSA62368-1, TUV (EN62368- 1), CE mark (for LVD) and CB report available
  • ISO 9001 and ISO 14001 certified manufacturing facilities
  • Conformal coated
