New polymer hybrid capacitors with highest tech spec

7th September 2023

Panasonic

Sheryl Miles

0 0

The newly introduced ZUU series of conductive polymer hybrid aluminium electrolytic capacitors from Panasonic Industry benefit from some of the best technical specifications currently available on the market for this type of capacitor.

ZUU series components feature the highest ripple current handling capability of 6.1 Arms maximum (a 60% increase over our previous series) at both 125°C and 135°C, together with the largest capacitance value of 1,000μF maximum (an 80% increase over our previous series) and the lowest ESR value of 8mΩ minimum. The lifetime of the capacitors is also very good with 4,000h at both 125°C and 135°C.

Fully AEC-Q200 compliant, ZUU series polymer hybrid capacitors are ideal for use in several ‘under the hood’ automotive applications like pump, electric power steering, cooling fans, high current DC to DC converter and ADAS.

Further target applications are telecommunications (DC to DC converter and AC to DC converter in base stations, servers, routers and switches), industrial (inverter power supply in robotics) as well as general power supplies (DC side of both inverter and rectifier circuits). Upon request also vibration-proof variants of ZUU capacitors with 6mm diameter or greater are available These devices can withstand shocks of as much as 30G. Standard parts can withstand 10G maximum.

With several production sites around the world, Panasonic Industry offers high production capacity for polymer hybrid capacitors, ensuring lead times are as short as possible.
