HVCB high voltage precision thick film chip resistors

16th October 2023
Harry Fowle

HVCB high voltage precision thick film chip resistors with high accuracy are now in stock at Stackpole.

High-voltage applications frequently require high-voltage resistors with high accuracy for voltage division, monitoring, and control. Some applications with more moderate working voltages may experience high voltage surges which may damage general purpose chip resistors. Finding a resistor for these requirements in stock can be challenging.

Stackpole’s HVCB series of thick film precision high voltage resistors have more than 90 parts in stock in the most popular sizes and values to facilitate rapid design and prototyping for high voltage electronics.

The HVCB series from Stackpole provides a high precision, low VCR chip resistor with high stability. The HVCB is available in resistance values from 10K to 50G, in tolerances as low as 0.1% and TCR as low as 25 ppm.

This precision high voltage performance is ideal for applications such as high voltage power supplies, voltage dividers, and a variety of medical applications such as patient monitoring, medical imaging, instrumentation, defibrillators, as well as applications for test and analysis, and data acquisition/communication / and monitoring.

Pricing varies with size, tolerance, TCR and resistance. Contact Stackpole or one of its franchised distributor partners for specific pricing.
