The Model 2100HF incorporates an all-solid-state design for high reliability and low-noise operation, thus achieving accurate output response and high slew rates, even into highly capacitive loads. Full power frequency response of the amplifier is essentially flat up to 2 MHz. No overshoot or instability of the waveform occurs due to the amplifier’s unique dual feedback feature.
DC to greater than bandwidth capabilities for the ±150 volt range include large signal bandwidth of 2.6 MHz. (-3 dB) and a small signal bandwidth greater than 3 MHz (-3 dB).
Industrial applications include the use with MEMS devices, electro-optic modulators, ion beam control, ultrasonics, dielectric material characterization, piezo electric driving and control.
