5 kW AC/DC power supplies with four VDC outputs

Excellent power density, high efficiency, industrial and medical safety approvals, Class B conducted emissions, and SemiF47 compliance make the HPT5K0-L suitable for a wide range of semiconductor, industrial, and medical applications.

The HPT5K0-L offers digital controls and monitors, constant current/constant voltage operation, and a graphical user interface (GUI)-enabled customer development, allowing designers to seamlessly integrate the product into their systems.

HPT5K0-L is scalable up to 30 kW and beyond when used in parallel and up to 400 V_DC in series configuration.

Features are:

• 5 kW fan-cooled output
• Output voltages of 48 V, 60 V, 100 V, and 200 V
• Programmable constant voltage (0% to 105%) and constant current (0% to 110%)
• Parallel operation for up to five units with sync connection for simultaneous output turn-on
• 3-phase 180 V_AC to 528 V_AC input – 3 wire and earth
• ITE and medical safety agency approvals
• Class B conducted and Class A radiated emissions

• High efficiency, up to 93%
• 5 V 2 A standby output
• Intelligent fan speed control
• Optimized slew rates <40ms
• Multiple digital protocols: I²C PMBus, CANopen, MODBUS, and SCPI
• GUI
• SEMI F47 compliant
• -20°C to +70°C operating temperature

Applications cover:

• Test and measurement
• Factory automation
• Medical imaging
• RF healthcare
• Battery charging
• Magnet drivers

• Burn-in
• Additive manufacturing
• Motor drivers
• Lasers
• UV curing
• 3D printing
