Schottky bridge rectifiers in low profile BR DFN package
Central Semiconductor has introduced its newest family of Schottky bridge rectifiers, the CBRDFSH series, available in one to two amp, and 40 to 100V options. Devices are packaged in the low profile BR DFN surface mount case and feature highly desirable energy efficiency. These full wave bridge rectifiers utilise individual glass passivated die to reduce leakage and improve performance and reliability.
These devices feature forward voltage (VF) as low as 500mV. The BR DFN package is 1.2mm in height, 54% lower than the comparable HD DIP, ensuring that low board profile is maintained. CBRDFSH series devices are ideal for applications requiring a space saving and energy efficient Schottky bridge rectifier, including Power over Ethernet (PoE), intelligent lighting, and power adapters.
The series includes the following devices:
- CBRDFSH1-40 (1A, 40V)
- CBRDFSH1-60 (1A, 60V)
- CBRDFSH1-100 (1A, 100V)
- CBRDFSH2-40 (2A, 40V)
- CBRDFSH2-60 (2A, 60V)
- CBRDFSH2-100 (2A, 100V)
Pricing for the CBRDFSH1-40 starts at $0.182 for 5,000 pieces on 13” tape and reel directly from Central.
