Pasternack launches new waveguide mixers, detectors, and couplers

3rd February 2023
Harry Fowle
0

Pasternack has just introduced a selection of in-stock, waveguide mixers, detectors, and couplers. They are made for a variety of applications, including 5G, 6G, test and measurement, research and development, electronic warfare and more.

Pasternack’s waveguide mixers, waveguide detectors, and waveguide couplers ship from an ISO 9001:2015-certified facility and feature rugged designs constructed from the highest quality materials to stand up to years of use.

The new couplers provide coupling values from 20-50 dB, waveguide sizes ranging from WR-28 to WR-229, and integrated connectorised designs with SMA, N-type and 2.92mm female connectors.

Pasternack’s new waveguide mixers provide low conversion loss ranges from 8-12dB with +13dBm LO drive. They also cover broadband frequencies from 26.5-110 GHz and LO-RF at 28dB typical.

The waveguide detectors are engineered with high levels of video sensitivity that range from 750-1500mV/mW with a wide dynamic range from -55dBm to +10 dBm and maximum input power of +17dBm.

“Our versatile portfolio of waveguide mixers, detectors, and couplers is engineered for high reliability in a variety of RF applications. Our customers will enjoy peace of mind, years of usefulness and best-in-class lead times with these new waveguide products,” said Tim Galla, Product Line Manager.
