Avalue is launching 2.5 inch Pico ITX embedded SBCs, EPX-EHLP

Avalue is bringing the new 2.5” embedded single board computers,EPX-EHLP, with Intel Pentium/Celeron/Atom SoC BGA Processor (Elkhart Lake Platform 4.5~12W), CPU bottom mounted, with huge improvement on performance and bug step ahead with Intel UHD Graphics target entry-level application market.

With improved performance, I/O capability, and security features, is the ideal SBC for industrial automation, retail, smart city, and IoT solutions.

2.5” Pico ITX SBC EPX-EHLP features flexible I/O supports 2 x USB 3.1 Gen.2, 4 x USB 2.0, 1 x RS-232, 1 x RS-232/422/485 with DC power input 12V. It supports dual stack DP display and LVDS for all kinds of applications.

This SBC design with one M.2 expansion slot: M.2 B-Key SATA/PCIe/USB supports storage and E-Key support Wifi module, USB2.0 signal. Also, EPX-EHLP offers dual Intel 2.5 Gigabit Ethernet.

EPX-EHLP main features:

• Onboard Intel Celeron/Atom SoC BGA Processor (Elkhart Lake Platform) (with CPU Bottom Mounted)
• One 260-pin DDR4 2666MHz SO-DIMM socket, supports up to 32GB Max (Only Atom® x6000 Series Processors support IBECC)
• Display: Dual stack DP, LVDS
• Expansion Slot: M.2 Key-B for storage SSD, M.2 Key-E for Wifi module.
• Dual Intel 2.5 Gigabit Ethernet
• Dual deck USB3.2 Gen 2 at IO, 4 x USB 2.0 by pin header, 1 x RS232, 1 x RS232/242/485
• GPIO 4bit
• DC in +12V

EPX-EHLP main applications:

• Industrial and factory automation
• Retail, digital signage, KIOSK
• Infotainment
• Hand-held PDA
