Amphenol RF is pleased to introduce 2.92mm to SMA adapters into our portfolio of coaxial adapters suited for testing purposes. These adapters are available in a variety of configurations including plug to plug, plug to jack, jack to plug and jack to jack. 2.92mm to SMA adapters offer high-frequency performance up to 26.5GHz which supports broadband applications such as network and spectrum analysis, and RF production tests.
Featuring an air-dielectric interface, these adapters minimise signal loss and maintain low VSWR for optimal measurement accuracy. The −65 to +165°C temperature range ensures functionality in a variety of harsh laboratory and field conditions. Designed with MIL-STD-348 compliant interfaces, these adapters are compatible with standard SMA and 2.92mm (SMK) connectors. The body and coupling nut are machined from passivated stainless steel and feature a contact made from gold-plated beryllium copper. The retaining ring is SUS 304 with a silicone gasket, and the 2.92mm insulator is made from PTFE while the SMA insulator is made from Ultem 1000. These adapters are suited for laboratory test benches, RF/microwave production tests, communications and radar system evaluations and high-frequency module characterisation.
This new off-the-shelf solution joins a broad offering of adapters designed to meet the increasing need for high-frequency data transmission in next-generation designs.
