Two-part structural epoxy meets ISO 10993-5 for non-cytotoxicity

9th February 2024
Sheryl Miles

Master Bond Supreme 11AOHTMed is a two-component epoxy featuring thermal conductivity and electrical insulation.

This system fully passes ISO 10993-5 testing for non-cytotoxicity and is recommended for bonding and sealing in medical device applications.

Supreme 11AOHTMed has reliable electrical insulation properties with a volume resistivity exceeding 1014 ohm-cm at 75°F. It also exhibits thermal conductivity of around four to five BTU·in/ft²·hr·°F (0.58-0.72 W/m/K). The system provides high bond strength properties with a lap shear strength of 3,200-3,400 psi, a tensile strength of 7,000-8,000 psi and a compressive strength of 20,000-22,000 psi. This toughened formulation is designed to withstand thermal cycling and offers a wide service temperature range from –112°F to +400°F (–80°C to 204°C).

Supreme 11AOHTMed cures at room temperature in 24–36 hours, and faster with heat, in 1–2 hours at 200°F. To optimise properties, the recommended cure schedule is overnight at room temperature, followed by a post cure at 120–150°F for 2–3 hours or preferably longer. It bonds well to a wide variety of substrates including metals, ceramics, glass, rubbers, and many plastics. This epoxy system has a convenient 1:1 mix ratio by weight, with the mixed material being a thixotropic paste. To eliminate the need for manual measuring and mixing, it can be packaged in double barrel cartridges for gun kits. It is also available in standard jars and cans, ranging in size from ½ pint to gallon containers.

Master Bond Adhesives for medical device manufacturing

Supreme 11AOHTMed is a thermally conductive, electrically isolating epoxy offering high strength and a wide service temperature range. This two-component epoxy passes ISO 10993-5 certification for non-cytotoxicity and is well suited for a variety of bonding and sealing applications in medical device assembly.
