Heraeus Electronics develops new production-friendly flexible end termination ink

29th March 2023
Harry Fowle

Heraeus Electronics is pleased to announce the development of a production-friendly, flexible passive component termination ink.

ET2010 Flexible End Termination Ink is utilising advanced polymer technology. When compared to current thermoset, epoxy-based inks in the market, Heraeus’ solution offers easier shipping, storage, and handling at room temperatures.

Manufacturers of passive electronic components, such as multi-layer ceramic capacitors, chip inductors, chip varistors, chip resistors and chip fuses are accustomed to handling electrode and termination inks in room temperature conditions, except for their flexible termination inks. Current flexible termination inks use epoxy-based, thermoset polymers that require deep freezing and special handling conditions to keep the epoxy from reacting.

Passive component requirements continue to grow with increased usage, especially in the Automotive, Consumer, and Industrial electronics industries.  In Automotive, current ICE automobiles contain 2000-3000 capacitors for example. This will grow by 5-10x (15-20k capacitors) in EVs, and brings further focus on reliability and safety given media and financial impacts from product recalls. This also is applicable for nearly all other high-reliability applications where impact testing, vibration, or thermal stability are concerns.  The value (pricing) of these high-reliability components is expected to increase as well.

Heraeus’ new ET2010 can provide these improvements in reliability as well as provide a production-friendly solution to the industry standard epoxy materials. The cost of ownership for the customer was kept fully in mind during development – shelf life, shipping, storage, paste utilisation, and scrap savings on silver are all improved compared to current materials.

The easy-to-use, reworkable ET2010 ink offers room temperature stability for six months, a significant benefit compared to epoxy-based pastes that need to be frozen or refrigerated. The optimised chemistry is composed of high-temperature thermoplastic instead of thermoset (epoxy) – making it more tolerant to thermal cycling and offering enhanced flexibility. With ET2010 there is no need for ice packs/dry ice, which translates to lower shipping costs, a low scrap rate (Ag savings), as well as eliminating costly storage. Additionally, its low silver (Ag) content – approximately 5-10% lower Ag content – provides significant savings given today’s Ag market pricing.

A drop-in solution, ET2010 stands for improved reliability with superior bend test capability of up to 10mm with minimal electrical property change, in addition to providing excellent moisture resistance and solder heat resistance.
