It combines level monitoring with RS-485 real time level messaging. The Smart 485 family is chemically compatible with a wide variety of liquids – gasoline, diesel fuel, oils, urea (Adblue), water, wastewater, ethanol, hydraulic fluid, and engine coolants. It was designed for non-contact liquid level or industrial process control applications to 85°C. The Smart 485 can be used in general industrial, heavy duty vehicle, diesel engine generators, and mining, agriculture, water and waste water markets.
The Smart 485 was designed to allow the user maximum flexibility with its user programmable features. Accurate level volume measurements are dependant on the shape and dimensions of your tank. The Smart 485 is programmable to allow for non-linear flexible tank profiling.
Other user programmable selections enable the Smart 485 to be configured for a wide variety of response times, sensing ranges and full and empty limits. The digital filtering can be used to eliminate errors due to fluids sloshing in mobile tanks. The gauge drive output can be used to specify full and empty endpoints that best suit your application needs.
The Smart 485 meets NEMA4 standards and has three different electrical outputs choices to best meet your application need – 4-20mA; ratiometric voltage (0.5 – 9.0V); and non-ratiometric voltage (0.5 – 9.5 V).
