The combiner box assembly consists of a box, cover with hinges, transparent dead front lid under the cover, and 10 pre-terminated SOLARLOK connectors each with a removable seal cover. The box features 4 knockouts for output wiring, lock tab, mounting slots, and pre-wired grounding clip. The device converts to standard THWN-2 wire in conduit.
The interior of the box holds five fuse blocks pre-wired to the positive SOLARLOK connectors, five terminal blocks pre-wired to the negative SOLARLOK connectors, and an equipment terminal block used to ground the equipment.
