It is based on the Telesto-III (2609011091000) radio module from Wurth Elektronik. Operating in the 902.5 to 927.5MHz ISM band (centred at 915MHz), the module supports a data rate of up to 400kbit/s, with a typical receiver sensitivity of -74dBm and transmission output power of -8dBm.
It communicates with the host MCU via UART and features integrated support for flow control, reset, boot, and mode selection.
With a line-of-sight range of approximately 40 meters and built-in antenna, it ensures dependable RF connectivity without complex setup.
ISM 8 Click is ideal for industrial automation, smart sensor networks, and remote monitoring applications that require low-power, point-to-point or multi-node wireless communication.
ISM 8 Click is fully compatible with the mikrobus socket and can be used on any host system supporting the mikroBUS standard. It comes with the mikroSDK open-source libraries, offering unparalleled flexibility for evaluation and customization.
Setting this click board apart is the groundbreaking ClickID feature, enabling the user’s host system to seamlessly and automatically detect and identify this add-on board.
