X-Fab unveils 110nm BCD-on-SOI process

5th June 2023
Mick Elliott

X-FAB Silicon Foundries SE says it has built on its position in BCD-on-SOI technology, by being the first foundry to introduce a 110 nm solution.

The new XT011 BCD-on-SOI platform reflects the growing need for greater digital integration and processing capabilities within analogue applications.

It brings together the appealing attributes associated with both SOI and DTI, so that high-density digital logic and analog functionality can be more easily incorporated in a single chip compared to traditional bulk BCD.

By moving to a lower process node, the X-FAB XT011 offering provides double the standard cell library density of its established XT018 180 nm BCD-on-SOI semiconductor platform. It also takes up 35% less area for SONOS embedded flash implementations. Ultra-low on-resistance (R(ds)on ) high-voltage N-channel device performance is another important property (with a greater than 25% improvement on the XT018 process).

The thermal performance has been enhanced significantly, which means that high-current applications can be better addressed – matching what would normally be expected of a bulk BCD process.

Enabling the delivery of AEC-Q100 Grade 0 compliant design implementations, this new BCD-on-SOI technology is highly robust. An operating temperature range of -40°C to 175°C is covered. Elevated levels of resilience to EMI are exhibited too. With no parasitic bipolar effects being witnessed, the risk of latch-ups occurring can be eliminated – thereby assuring the highest degrees of operational reliability.

A comprehensive process design kit (PDK) provided by X-FAB for XT011 as well as a broad array of IP elements, such as SRAM, ROM, SONOS-based flash and embedded EEPROM, are available. Thanks to this, customers will have all the means they need to achieve ‘first-time-right’ designs – which will translate into quicker time to market.

The XT011 process is primarily targeted at next-generation automotive applications that require an increased level of data processing capabilities. In addition, it will provide a path to a smaller geometry for existing industrial and medical products.

“X-FAB is already widely known as the go-to foundry for BCD-on-SOI technology, and being the first to transition to 110 nm further highlights our unmatched expertise in this field,” states Joerg Doblaski, CTO of X-FAB. “Through this next generation automotive-grade process, we are providing customers the foundation they require for producing more sophisticated, highly integrated smart analogue products.”

Devices using the new XT011 110 nm BCD-on-SOI semiconductor process will be fabricated at X-FAB’s facility in Corbeil-Essonnes, near Paris.

Volume production will commence in the second half of 2023.
