New version of Flex Power Designer Software released

This upgrade underscores the company’s commitment to innovation and enhanced support for the evolving needs of power system designers. Uniquely, the tool continues to provide the ability to include generic products, not limited to those from Flex Power Modules, and remains free for all users.

Version 4.6 brings a suite of advanced features and improvements, further establishing Flex Power Designer as an indispensable resource for designing sophisticated power supply systems. Key updates include enhancements to phase spreading, droop simulation, a more compact system view, and support for USB-TO-GPIO2.

Enhanced phase spreading capabilities

Flex Power Designer now offers full support for the company’s 40A rated BMR473 and 80A rated BMR474 DC/DC Point of Load regulators when applying Phase Spreading. The update enables designers to optimise power distribution and minimise noise in their systems, ensuring optimal performance and overall system reliability.

Advanced droop simulation

With the introduction of droop settings in the frequency analysis for the 1,600W rated BMR351 intermediate bus converter, users can now simulate and adjust droop responses more accurately. This feature is crucial for maintaining stability and performance under varying load conditions, providing designers with the capability to fine-tune their power systems.

Compact system view

Understanding the importance of a streamlined design process, Version 4.6 introduces a compact system view. This upgrade offers a clearer overview of the system design, enabling easier navigation and adjustments to help speed up the development cycle.

Integration with TI’s latest PMBus adapter

Recognising the need for seamless compatibility, the update includes support for Texas Instruments’ latest PMBus adapter, USB-TO-GPIO2. This integration facilitates easier communication and configuration of power modules, further simplifying the design process for engineers.

Initially launched in 2012 to complement the company’s digital DC/DC converters, Flex Power Designer was the first power designer software of its kind. A free copy of the software tool can be downloaded from the Flex Power Designer website.

Flex Power Modules will showcase Version 4.6 of the Flex Power Designer at embedded world 2024, taking place in Nuremberg, Germany, from 9–11 April 2024. Additionally, at booth 208A in Hall 4, the company will present its latest DC/DC converters for industrial and transportation applications, alongside products for the telecom and 5G sectors, RFPA applications, and solutions involving intermediate bus converters and voltage regulator modules tailored for AI and cloud computing.
