Enedo’s new medical and industrial range
Enedo Power introduces the MDP520 and DDP520 series of power supplies, which are capable of a long lasting 520W peak and a steady 460W power in a 3 x 5” open frame footprint.
There is also a protective cage option to ease installation and provide safety protection.
Being optimised to operate at free-air cooling environment it also offers up to 330W at 50°C ambient temperature, especially suitable for medical applications where silent operation is essential.
The MDP/DDP520 power supplies work worldwide over 90 to 305 VAC input voltage range.
With 94% efficiency, less than 0.35W standby power consumption, and greater than 0.9 power factor in every working condition, the series ensure compliance with the latest power supplies Eco-Design regulations. They come with 24, 36, 48, and 56 VDC standard output variants.
The MDP520 medical version, certified to IEC / EN / UL 60601-1, offers 2xMoPP means of patient protection and is BF medical equipment compatible.
Key features:
- 90–305 VAC universal input voltage range
- 460W rated power; 330W free-air cooled
- 520W peak power – 10ms
- High efficiency to 94.5%
- 24, 36, 48, and 56 VDC standard output variants
- +5V 1A stand-by output
- Active PFC, EN 61000-3-2
- Class C, >20% load
- Low earth leakage current
- Safety certification process ongoing
