Specifications: Contact arrangement is 1A SPST N.O. with contact rating of 20A 14VDC N.O. Contact
resistance is less than 50 milliohms; contact material is AgSnO2. Tested electrical life of the A17 Series is 100k cycles with mechanical life of 10M cycles. The dielectric strength is 750Vrms minimum coil to contact and 500Vrms minimum contact to contact. Insulation resistance is 100M minimum at 500VDC. Shock resistance is 98m/s2 for 11 ms and vibration resistance is 1.5mm double amplitude 10~55Hz. Operating and storage temperature is -40°C to 85°C. Solderability is 260°C for 5s. Weight is 13g.
The A17 Series relays are ideal for controlling lamps and motors, among other automotive applications. Pricing ranges from $0.82 dependent upon options and volume. Contact CIT Relay & Switch for lead-time information.
